- Max Height (mm)
- Thickness (mm)
- Acoustics (dB)
- Fire Rating
- Weight (Kg/m^2)
Maximising the transfer of Daylight, with ultimate performance.
This fully glazed screen with minimalist detailing, maximised the flow of light whilst providing high levels of performance.
Single glazed, this screen can accommodate a number of glass specifications to offer impressive acoustic solutions for a wide selection of applications. Fully glazed, framed glass or solid doors are available.
With its impressive 99.9% glass, Deko FG screens are also 100% recyclable.
Two joint options are available:
- Provides a stable, soundproof partition with an almost invisible, prefabricated, clear joint.
ALUMINIUM PROFILE JOINT
- Lends the partition character, and the screen 100% relocatable using a slim aluminium vertical trim.
Detail of Deko FG
|PRODUCT TYPE||CONNECTION TYPE||SOUND INSULATION||OVERALL THICKNESS||GLASS THICKNESS||TOTAL WEIGHT||FIRE RESISTANCE|
|DEKO FG||Profile||34-40 dB||27 mm||10, 12 mm||20-35 kg/m²||Unclassified||View Details|
|DEKO FG||Profile||36-42 dB||30-32 mm||15, 17 mm||38 - 43 kg/m²||Unclassified||View Details|
|DEKO FG||Clear||34-40 dB||27 mm||10, 12 mm||20 - 35kg/m²||Unclassified||View Details|
|DEKO FG||Clear||36-42 dB||30-32 mm||15, 17 mm||38 - 43 kg/m²||Unclassified||View Details|
